Features
- Ultra High Efficiency AURA Collection (With ENERGY STAR)
- DC Inverter Compressor -Variable speed compressor helping unit draw less electricity, produce less sound and gives you better room temperature control
- Silver Ion Filter – Reduce allergens and bacteria in the air with a seven-stage air filtration system, to help eliminate odors, and up to 95% of smoke and pollen
- With Heating – Can heat your home, bedroom, office, or store all year round, with heating and cooling up to -22F/-30C
- Follow Me Technology - Built-in sensor technology follows the remote control's location and provides the most comfortable temperature to that area
- Ultra Quiet Operation - Special cross-flow technology with a larger diameter helps to reduce noise levels without sacrificing airflow or cooling, making the system whisper quiet
- Not Included: Electrical wiring needed for installation and drain pipe
- Included: 16 Ft. Copper Line Set Kit for Each Indoor Handler
BTU Sizing Chart for Mini Split Systems
Check out our square footage and BTU comparison chart below. The following table is for individual zones, for a multi-zone, combine the total BTU’s needed to establish the overall BTU values of the system.
| Area To Be Cooled |
Capacity Needed (BTUs Per Hour) |
| 150 to 250 square feet |
6,000 BTUs |
| 250 to 300 square feet |
7,000 BTUs |
| 300 to 350 square feet |
8,000 BTUs |
| 350 to 400 square feet |
9,000 BTUs |
| 400 to 450 square feet |
10,000 BTUs |
| 450 to 550 square feet |
12,000 BTUs |
| 550 to 700 square feet |
14,000 BTUs |
| 700 to 1,000 square feet |
18,000 BTUs |
| 1,000 to 1,200 square feet |
21,000 BTUs |
| 1,200 to 1,400 square feet |
23,000 BTUs |
| Up to 1,500 square feet |
24,000 BTUs |
Key Product Features
- 22.5 SEER
- With Heat Pump (Up to -30C / -22F)
- Energy Star Certified
- Whisper Technology (Ultra Quiet)
- Refrigerant Leak Detection
- Inverter Technology
- Silver Ion Filter (Anti-Microbial)
- Vertical Swing Function
- Built-In De-humidification Function
- Follow Me Function (Remote with Built-In Thermostat)
- Low Ambient Cooling (Up to -30C / -22F)
- Self-Cleaning Mode
- PTC Heat Belt and Pan
- Bucket Free Outdoor Design
- Self Diagnosis SystemTechnical Specifications
| Model Number |
SENA/36MO/Z-IC |
| Style |
Ductless Mini Split AC With Heat Pump |
| Compressor |
Toshiba (GMCC) |
| Refrigerant |
R410A (Pre-Charged) |
| Refrigerant Pre Charge |
25 Ft. |
| Cooling Capacity |
36000 BTU |
| Heating Capacity |
36000 BTU |
| Air Flow |
Varies According To Indoor Combination |
| Power Supply |
208-230 V / 60 Hz, 1Ph |
| Input Power |
880-4160W (Cooling) / 960-3795W (Heating) |
| Input Current |
N/A |
| SEER |
22.5 |
| EER |
11.5 |
| HSPF5 |
8.7 |
| Sound Level |
43/36/24 dB (Indoor) / 62.3dB (Outdoor) |
| Moisture Removal |
1 L/hr |
| Min Operating Temperature |
– 30 C / –22 F |
| Net Weight |
19 .84 Lbs (Indoor)/ 71 lbs (Outdoor) |
| Dimensions |
22.44×22.44×10.24 in (Indoor Unit) 37.24×16.14×31.89 in (Outdoor Unit) |
| Warranty |
2 Year on Parts / 7 Years on Compressor |
| Connection Wiring (Indoor/Outdoor) |
16AWG-4 Stranded, Unshielded |
| Connection Wiring (Power Supply) |
10-3 Guage |
