KFUF036-H2G1 | Indoor Unit
Extremely quiet operation and rugged construction make the 48,000 BTU KFUF048-C2 220 volt fan coil unit by Klimaire ideal for heavy traffic and public areas. It arrives pre-vacuumed and can be installed on the ceiling, low on a wall or on the floor. Includes slide out washable air filter and wireless remote control. Choose from cooling, fan and dehumidification modes. Features 24-hour timer, sleep mode and auto restart.
Directional air flow: Using the included remote control, manually adjust the airflow direction or set the unit to auto swing. This ensures that your commercial space is cooled evenly and prevents a continuous blast of cold air in one direction. This is especially important in commercial applications such as hydroponic indoor gardens or restaurants, both of which are ideally suited for commercial mini-split air conditioner systems.
- Adjustable airflow with wireless LED remote
- Auto swing louvers
- Auto restart after power failure
KSIR036-H218 | Outdoor Unit
Automatic defrost prevents condensation from freezing and damaging the compressor. The built-in base pan heater ensures reliable operation in temperatures as low as 5º F. A built-in crank case heater protects your compressor lifespan. Compact outdoor unit requires little ground space and can be mounted to a wall with wall brackets (not included). Pre-charged for up to 25 feet of refrigerant piping.
- Refrigerant leak detection
- Double cam twin rotary compressor
- Auto defrost, base pan heater plus crank case heater
Additional Features
- EER (Energy Efficiency Rating): 8
- Refrigerant lines sizes: Liquid side: 3/8" ; Gas side: 5/8"
- Anti-cold air function
- Full-function remote control and built-in emergency MANUAL switch button
- Indoor unit has multi-refrigerant outlet pipes: left/right/rear
- ON/OFF programmable timer
- Optional wired wall thermostat can be plugged-in easily for commercial or non-remote control use
- Indoor unit is pre-vacuumed and outdoor unit is pre-charged
Applications
- Sunrooms
- Greenhouses
- Indoor gardens / hydroponic gardening
- Room additions to homes or offices
- Churches
- Fitness Centers
- Renovations
- Family rooms
- Wine cellars
- Garages/workshops
WHAT’S INCLUDED
- KFUF036-H2G1 | Indoor Unit
- KSIR036-H218 | Outdoor Unit
- Remote Control With Wall Bracket Holder
- Indoor Unit Wall Mounting Bracket
- Installation Manual
- User’s Manual
- Manufacturer Warranty
- 15 FT Lineset
MANUFACTURER WARRANTY
- 1 year parts limited warranty
- 5 years compressor limited warranty
Key Specifications
| Brand |
Klimaire |
| Model Number |
KSIR036-H218 + KFUF036-H2G1 |
| Indoor Model Number |
KFUF036-H2G1 |
| Outdoor Model Number |
KSIR036-H218 |
| Application Area |
2400 SqFt |
| Number of Zones (Rooms) |
1 |
| Cooling Capacity |
36000 Btu/h |
| Heating Capacity |
38000 Btu/h |
| Mounting Type |
Floor/Ceiling |
| Application |
Heat Pump/heating & cooling |
| Efficiency (SEER) |
16 |
| Control Voltage |
208/230 Volt |
| System Shipping Weight |
243 lbs |
| Manufacturer Limited Warranty |
1 year parts 5 years compressor |
